Product features:
1. The dispenser is a brand new dispenser designed for spray valve;
2. Independent adjustment of spray air pressure to accurately control the atomization effect;
3. It has the function of adjusting the delayed disconnection of atomization air pressure, providing better glue dispensing at the end of atomization;
4. It can independently adjust and control the movement pressure of the spray valve, which can be controlled by single action or interaction:
5. Using digital buttons to set and LED display time, intuitive and convenient, with an adjustment range of 0.01s to 99.99h;
6. It has the function of cyclic dispensing, which can achieve automatic dispensing of glue at intervals required by automated production lines;
7. The precise dispensing system ensures that high-quality dispensing requirements are met, and the valve achieves glue switch, ensuring that the glue does not leak.
Applicable glue:
Adhesive, alcohol, white latex, three proofing paint, diluent, medicament, paint, ink, UV adhesive, etc.
| Technical Parameters | |
| Time display | Four position LED display |
| Glue release time | 0.01S～99.99S |
| Interval time | 0.1S～9.9S |
| In put pressure | 0.5Mpa–0.7Mpa Dry compressed air |
| Output pressure | 0.01Mpa–0.7Mpa |
| Repetitive accuracy | ±0.1% |
| Minimum infusion volume | 0.005ml |
| Working speed | >200 times/minute |
| Power supply | 220V±10% 50Hz |
| Total power | <15W |
| Weight | <3Kg |
| Functional mode | Manual mode/Quantitative mode/Cyclic mode |
| Action signal | Foot switch or manual switch optional |
